Omron FQ2-S Series User Manual

Command Control
220
FQ2-S/CH User’s Manual
for Communications Settings
*1 The value about the shutter speed is the following.
*2 The value about the gain is the following.
8 Y coordinate of the partial
input end point
The following ranges depending
on the processing resolution of
the Sensor's internal camera.
*3
0.3M: 7 to 479
0.8M: 105 to 925
1.3M: 7 to 1,023
Reduces the range of the image to
input.
Specify the X and Y coordinates of
the start point and end point.
9 Lighting status 0: Lighting OFF
1: Lighting ON
Specifies the lighting status of the
built-in lighting for Sensors with
Built-in Lighting.
10 White balance R scaling 0.001 to 7.999
11 White balance G scaling 0.001 to 7.999
12 White balance B scaling 0.001 to 7.999
257 Trigger delay 0 to 163,830 Specifies the time until the camera
shutter opens after the trigger con-
dition is satisfied. (Unit: μsec)
Model Range
FQ2-S3@@-13
FQ2-S3@@-13M
FQ2-S4@@-13
FQ2-S4@@-13M
1/1 to 1/4,155
FQ2-S3@@@@@-08
FQ2-S3@@@@@-08M
FQ2-S4@@@@@-08
FQ2-S4@@@@@-08M
1/1 to 1/4,155 (Built-in lighting off)
1/250 to 1/60,000 (Built-in lighting on)
FQ2-S1@@@@@
FQ2-S2@@@@@
FQ2-S4@@@@@
FQ2-S4@@@@@-M
FQ2-CH1@@@@@-M
1/1 to 1/50,000 (Built-in lighting off)
1/250 to 1/50,000 (Built-in lighting on)
Model Range
FQ2-S3@@@@@-08
FQ2-S3@@@@@-08M
FQ2-S3@-13
FQ2-S3@-13M
FQ2-S4@@@@@-08
FQ2-S4@@@@@-08M
FQ2-S4@-13
FQ2-S4@-13M
0 to 10
FQ2-S1@@@@@
FQ2-S2@@@@@
FQ2-S4@@@@@@
FQ2-S4@@@@@@-M
FQ2-CH1@@@@@-M
16 to 64
Camera
parameter
number
Item Range Description
FQ2-S_CH_comm.book 220 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
