Omron FQ2-S Series - Page 227

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
225
5
Appendices
204 Parallel
Interface
Sensor
Data Unit
OR one-shot
output time
4 1 to 10,000 Specifies the output time
(x0.1 ms) when using one-
shot output.
205 Parallel
Interface
Sensor
Data Unit
Output control 4 0: No handshake
1: Handshake
2: Sync output
Specifies the control
method for output timing.
206 Parallel
Interface
Sensor
Data Unit
Output period 4 20 to 50,000 Specifies the period (x0.1
ms) for outputting mea-
surement results.
207 Parallel
Interface
Sensor
Data Unit
GATE ON delay 4 10 to 10,000 Specifies the ON delay
time (x0.1 ms) from when
outputting the results to the
parallel interface until out-
putting the GATE signal.
208 Parallel
Interface
Sensor
Data Unit
Output time 4 10 to 10,000 Specifies the time (x0.1
ms) the GATE signal output
is ON.
209 Parallel
Interface
Sensor
Data Unit
Timeout 4 5 to 1,200 Specifies the timeout time
(x0.1 s) when using hand-
shaking.
210 Parallel
Interface
Sensor
Data Unit
Number of
delay
4 1 to 15 Specifies the number of
delays when using syn-
chronized output.
211 Parallel
Interface
Sensor
Data Unit
ACK signal ON
period
4 1 to 10,000 Specifies the ACK signal
ON output time (x0.1 ms)
when outputting the ACK
signal.
251 RS-232C
Interface
Sensor
Data Unit
OR output 4 0: OK: ON
1: NG: ON
Specifies the polarity when
the OUT0 output signal is
ON. Overall judgements
are supported.
252 RS-232C
Interface
Sensor
Data Unit
Judgment out-
put mode
4 0: Level output
1: One-shot output
Specifies whether output is
one-shot output or level
output.
253 RS-232C
Interface
Sensor
Data Unit
OR output
delay time
4 0 to 10,000 Specifies the ON delay
time (x0.1 ms) until output-
ting the signal.
254 RS-232C
Interface
Sensor
Data Unit
OR one-shot
output time
4 1 to 10,000 Specifies the output time
(x0.1 ms) when using one-
shot output.
System
data num-
ber
Ty p e Item Data
size
Range Description
