Command Control
248
FQ2-S/CH User’s Manual
for Communications Settings
Load Model Dictionary Data
This command loads model dictionary data that is stored on the SD card inserted in the Touch Finder as the
model dictionary with the specified number.
The source for model dictionary data is the following fixed directory on the SD card.
\Sensor name\DIC
The file name is not case sensitive. The file name extension can be omitted.
Command (PLC to Vision Sensor)
*1 Loads the files named Dictionary_***.dic saved on the SD card. (***: Specified file number)
Response (Vision Sensor to PLC)
First word of com-
mand area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1100 0000 0000 0000 Command code
+3 0000 0000 0110 0000
+4 0000 0000 0000 0000 Model dictionary data number you want to load
(0 to 31)
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 • EtherNet/IP, PROFI-
NET
File number to load (0
to 999)
*1
• PLC link
File name to load
64 characters max.
The file name exten-
sion (.dic) can be omit-
ted.
+7 0000 0000 0000 0000
+8 0000 0000 0000 0000 ---
: ::::
+37 0000 0000 0000 0000
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1100 0000 0000 0000 Command code
The command code for which the response
applies is stored.
+3 0000 0000 0110 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
