Command Control
260
FQ2-S/CH User’s Manual
for Communications Settings
Save Latest Input Image Data
Saves the latest input image to the SD card inserted in the Touch Finder as ifz data.
The destination for image data is the following fixed directory on the SD card.
\Sensor name\CAPTURE\Number
*
*Number is a five digit number starting from 00000. The images are saved in increments of 100 images for each number, and when there
are over 100 images, the directory with the next number is created.
The file name is not case sensitive. The file name extension can be omitted.
Command (PLC to Vision Sensor)
*1 When using the EtherNet/IP or PROFINET communication protocol, the file name is automatically created as follows.
The date and time are not recorded in the image data.
Therefore, the date and time that make up the file name are not the date and time that the measurement was performed, they are the date
and time the image data file was saved from the Sensor to the Touch Finder SD card by this command.
Response (Vision Sensor to PLC)
Save Measurement Data
Saves measurement data saved in the Sensor's memory by the logging function to the SD card inserted in the
Touch Finder as csv data.
The destination for measurement data is the following fixed directory on the SD card.
\Sensor name\LOGDATA
The file name is automatically created as follows.
The date and time that make up the measurement data file name are not the date and time that the
measurement was performed, they are the date and time the measurement data file was saved from the
Sensor to the Touch Finder SD card by this command.
The file name is not case sensitive. The file name extension can be omitted.
First word of
command area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0100 0000 0010 0000 Command code
+3 0000 0000 0111 0000
+4 0000 0000 0000 0000 File name
*1
(only when using the
PLC link communication protocol)
File name to save
64 characters max.
The file name extension (.ifz) can
be omitted.
: ::::
+35 0000 0000 0000 0000
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0100 0000 0010 0000 Command code
The command code for which the
response applies is stored.
+3 0000 0000 0111 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
YYYY_MM_DD-HH_mm_ss.ifz
Date that the image data was saved to the Touch Finder SD card
Time that the image data was saved to the Touch Finder SD card
YYYY_MM_DD-HH_mm_ss.csv
Date that the measurement data was saved to the Touch Finder SD card
Time that the measurement data was saved to the Touch Finder SD card
