Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
261
5
Appendices
Command (PLC to Vision Sensor)
Response (Vision Sensor to PLC)
Save Statistical Data
Saves statistical data saved in the Sensor's memory by the logging function to the SD card inserted in the
Touch Finder as csv data.
The destination for statistical data is the following fixed directory on the SD card.
\Sensor name\LOGDATA
The file name is automatically created as follows.
The date and time that make up the statistical data file name are not the date and time that the measurement
was performed, they are the date and time the statistical data file was saved from the Sensor to the Touch
Finder SD card by this command.
The file name is not case sensitive. The file name extension can be omitted.
Command (PLC to Vision Sensor)
First word of
command area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0111 0000 0000 0000 Command code
+3 0000 0000 0111 0000
+4 0000 0000 0000 0000 File name
*1
(only when using the
PLC link communication protocol)
File name to save
64 characters max.
The file name extension (.csv) can
be omitted.
: ::::
+35 0000 0000 0000 0000
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 0111 0000 0010 0000 Command code
The command code for which the
response applies is stored.
+3 0000 0000 0111 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
First word of
command
area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1000 0000 0000 0000 Command code
+3 0000 0000 0111 0000
YYYY_MM_DD-HH_mm_ss_record.csv
Date that the statistical data was saved to the Touch Finder SD card
Fixed
Time that the statistical data was saved to the Touch Finder SD card
