Command Control
262
FQ2-S/CH User’s Manual
for Communications Settings
Response (Vision Sensor to PLC)
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1000 0000 0010 0000 Command code
The command code for which the
response applies is stored.
+3 0000 0000 0111 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
