Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
287
5
Appendices
<Parameter Descriptions>
*1 The regions are specified with the following values according to the image adjustment item (filter item/position compensation item) type.
Image adjustment item
(filter item/position com-
pensation item) number
Specifies the image adjustment item (filter item/position compensation item) number.
(0 to 7)
Region number Selects the regions. The value that specifies each region differs according to the image
adjustment item (filter item/position compensation item) type.
*1
Figure number The measurement region or model registration region range registers a complicated
model or a measurement region by combining a maximum of 8 figures (rectangles, cir-
cles, and other shapes).
With this command, specify the figure number of the figure with the parameters you want
to acquire out of the multiple figures.
Parameter 1 to parame-
ter 21
The items of information for the figure set as the model registration region or the mea-
surement region are split up and returned in parameter 1 through parameter 21.
*2
Image adjustment item
(filter item/position
compensation item)
type
Command arguments
Region number Figure number
Color Gray Filter 0 (Filter region) 0
Weak Smoothing 0 (Filter region) 0
Strong Smoothing 0 (Filter region) 0
Dilate 0 (Filter region) 0
Erosion 0 (Filter region) 0
Median 0 (Filter region) 0
Edge Extraction 0 (Filter region) 0
Extract Horizontal Edges 0 (Filter region) 0
Extract Vertical Edges 0 (Filter region) 0
Enhance Edges 0 (Filter region) 0
Background Suppression 0 (Filter region) 0
1 (Background suppression
calculation region)
0
Shape Search Position
Compensation
0 (Position compensation
region)
0
1 (model registration region) 0 to 7
2 (measurement region) 0
Search Position Com-
pensation
0 (Position compensation
region)
0
1 (model registration region) 0 to 7
2 (measurement region) 0
Edge Position Compen-
sation
0 (measurement region) 0
2 (Position compensation
region)
0
FQ2-S_CH_comm.book 287 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
