Command Control
298
FQ2-S/CH User’s Manual
for Communications Settings
<Parameter Descriptions>
Terminal type Specifies the type of terminal for the terminal status to be acquired.
• Sensor's standard parallel communications
0: TRIG
2: IN0 to IN5
• Parallel Interface Sensor Data Unit
0: TRIG
1: DSA
2: IN0 to IN7
13: RESET
• RS-232C Interface Sensor Data Unit
0: TRIG
2: IN0 to IN5
13: RESET
Ter m i n a l nu m ber Specifies the terminal number for the terminal status to be acquired.
• If the terminal type is IN0 to IN5
0: IN0 to 5: IN5
• If the terminal type is IN0 to IN7
0: IN0 to 7: IN7
• Cases other than the above cases
Specify 0
Acquired value Returns the acquired terminal status. (ON: 1, OFF: 0)
FQ2-S_CH_comm.book 298 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
To Next Page
