Omron FQ2-S Series User Manual

Command Control
346
FQ2-S/CH User’s Manual
for Communications Settings
LASTIMAGESAVE or LIS
Saves the latest input image to the SD card inserted in the Touch Finder as ifz data.
The destination for image data is the following fixed directory on the SD card.
\Sensor name\CAPTURE\Number
*
*Number is a five digit number starting from 00000. The images are saved in increments of 100 images for each number, and when there
are over 100 images, the directory with the next number is created.
<Command Format>
or
<Response Format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
• If the specified file name already exists, this existing file will be overwritten.
• Do not turn off power to the Vision Sensor until there is a response.
Image data file name Specifies the image data file name to save. (64 characters max.)
The file name extension (.ifz) can be omitted.
LAST IM GESAV EA
C
R
Image data file name
Space (0x20)
LIS
C
R
Image data file name
Space (0x20)
Delimiter
CR OK
CR ER
Delimiter
Important
