Save Commands for Binary Data Files
PRESCNSAVEB (Check) / SCNSAVEB (Execute)
Outputting scene data (binary data)
This command outputs scene data for the Sensor in binary data format.
To execute this command, two types of commands are used, a confirmation command and an execution
command.
For how to execute the command using the confirmation command and the execution command, refer to
Binary Data File Load and Save Commands: p. 183.
<Confirmation command format>
Before scene data in binary data format is output, a check is performed to determine if the data can be received
by the external device that will receive the data.
<Confirmation command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Execution command format>
This command outputs the scene data in binary data format.
PR SAVEB CR ES NC
Scene data number
Space
(0x20)
Delimiter
CR
Scene data size
Delimiter
CR OK
Delimiter
CR ER
Delimiter
SAVEB CR SNC
Delimiter
