Command Control
358
FQ2-S/CH User’s Manual
for Communications Settings
<Confirmation command format>
Before loading all model dictionary data in binary data format, the Sensor checks whether or not it can receive
binary data.
<Confirmation command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Execution command format>
Loads all model dictionary data in binary data format.
<Execution command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
File size scheduled to be sent Number of bytes of all model dictionary data scheduled to send (integer type)
All model dictionary data (binary) All model dictionary data to be loaded (binary data)
PR LOADB CR ED RG
File size scheduled to be sent
Space
(0x20)
Delimiter
Delimiter
CR OK
CR ER
Delimiter
LOADB CR DGR
All model dictionary data (binary)
Space
(0x20)
Delimiter
Delimiter
CR OK
CR ER
Delimiter
