When the Command Is Not Processed Normally
<Execution command format>
This command outputs all scene data in binary data format.
<Execution command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
PRESYSSAVEB (Check) / SYSSAVEB (Execute)
Outputting system data (binary data)
This command outputs system data for the Sensor in binary data format.
To execute this command, two types of commands are used, a confirmation command and an execution
command.
For how to execute the command using the confirmation command and the execution command, refer to
Binary Data File Load and Save Commands: p. 183.
<Confirmation command format>
Before system data in binary data format is output, a check is performed to determine if the data can be
received by the external device that will receive the data.
All scene data size Number of bytes of all scene data to output (integer type)
All scene data (binary) All scene data to output (binary data)
CR ER
Delimiter
SAVEB CR SRG
Delimiter
All scene data (binary)
Delimiter
CR OK
CR
Delimiter
CR ER
Delimiter
PR SAVEB CR ES SY
Delimiter
