Command Control
432
FQ2-S/CH User’s Manual
for Communications Settings
● Save Statistical Data: 280F 00708000
Saves statistical data saved in the Sensor's memory by the logging function to the SD card inserted in the
Touch Finder as csv data.
The destination for statistical data is the following fixed directory on the SD card.
\Sensor name\LOGDATA
The file name is automatically created as follows.
The date and time that make up the statistical data file name are not the date and time that the measurement
was performed, they are the date and time the statistical data file was saved from the Sensor to the Touch
Finder SD card by this command.
Format
Response Format
End Codes
Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F 00708000
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00708000
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
YYYY_MM_DD-HH_mm_record.csv
Date that the statistical data was saved to the Touch Finder SD card
Time that the statistical data was saved to the Touch Finder SD card
Important
