Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
431
5
Appendices
● Save Measurement Data: 280F 00707000
Saves measurement data saved in the Sensor's memory by the logging function to the SD card inserted in the
Touch Finder as csv data.
The destination for measurement data is the following fixed directory on the SD card.
\Sensor name\LOGDATA
The file name is automatically created as follows.
The date and time that make up the measurement data file name are not the date and time that the
measurement was performed, they are the date and time the measurement data file was saved from the
Sensor to the Touch Finder SD card by this command.
Format
Response Format
End Codes
Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F 00707000
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00707000
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
YYYY_MM_DD-HH_mm_ss.csv
Date that the measurement data was saved to the Touch Finder SD card
Time that the measurement data was saved to the Touch Finder SD card
Important
FQ2-S_CH_comm.book 431 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
