Omron G5 Series Startup Guide

12
6.2. Preparation for the Controller Setup
Prepare the Controller settings.
Install Power PMAC IDE on the computer in advance.
Creation of a New Project 6.2.1.
1
Turn on the power to the
Controller.
2
Start Power PMAC IDE.
* If the dialog for confirming
access rights appears upon
start-up, select starting of Power
PMAC IDE.
3
The Communication screen
appears. Specify the IP address
of the destination Controller and
click Connect.
* The IP address of the Controller
is set to “192.168.0.200” by
default.
* If necessary, change the
Windows IP address to
“192.168.0.X”.
4
Power PMAC IDE starts, and is
online to the Controller.

Omron G5 Series Specifications

General

Feedback	Incremental Encoder, Absolute Encoder
Communication	EtherCAT
Safety Function	STO (Safe Torque Off)
Protection Functions	Overvoltage, Undervoltage, Overcurrent
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
