Chapter 6: Connectivity
Figure 6-11. E-Stop Chain Diagram
Callout Description Callout Description
A Standard Circuits H Bumper Right
B User-Supplied Circuits J E-STOP Relay Control Logic
C E-STOP-Source K Voltage of the Battery
D Ground L High Power to Amplifiers
E Front Panel E-STOP M HMI Connector
F User E-STOP N Note: Jumper closed when not
used, MUST open both channels
independently if used.
14766-000 Rev H LD Cart Transporter User's Manual 101
