Omron LD-105CT - Cart; Docking Station

Chapter 11: Technical Specifications
Nominal Qty Actual
Maximum
Current
Description
12 VDC 1 12±5% VDC 1 A Switched Aux power
20 VDC 1 20±5% VDC 1 A Switched Aux power
22 – 30 VDC 2 battery 4 A Switched
22 – 30 VDC 1* battery 10 A Switched
22 – 30 VDC 1* battery 10 A Safe, Switched
* 10 A Switched and 10 ASafe, Switched share the 10 A of current.
Cart
Description Specification
Physical
Length 592 mm
Width 846 mm
Height 480 mm
Weight 23 kg (50 lb)
Rating
Caster ESD ESD rated
Suspension
Passive Casters 2 front, 2 rear, spring-loaded
Caster diameter 100 mm (4 inches)nominal
Caster Brakes 2 rear casters
Docking Station
Description Specification
Current 8 A, thermal fuse built into power switch
Contacts 2
Voltage 100-240 VAC, 50/60 Hz
Power consumption 800 W
Short circuit current
rating (SCCR)
1500 A
Humidity 5% to 95% non-condensing
Temperature 5 to 40°C (41 to 104°F)
Dimensions - WxDxH 349 x 369 x 315 mm
14766-000 Rev H LD Cart Transporter User's Manual 191
