Chapter 3: Setup
Figure 3-18. Docking Station, Mounted on Floor Plate
406
495
Figure 3-19. Docking Station Floor Plate Dimensions (units are in mm)
14766-000 Rev H LD Cart Transporter User's Manual 55
