86 LD Cart Transporter User's Manual 14766-000 Rev H
6.2 LD Platform Cart Transporter Connections
Pin No. Designation Notes
3 N.C.
4 SHIELDGND
User I/OOutputs, J19 - J26. Micro MATE-N-LOK, mates with TE 2C 794617-2.
The return is common for each bank of four outputs, with the indicated jumper.
Connector Designation Notes
J19 OUT1 JP13, LEDDS14
J20 OUT2 JP11, LEDDS15
J21 OUT3 JP10, LEDDS16
J22 OUT4 JP12, LEDDS17
JP26 RETURN Selects HI or LO for J19-J22
J23 OUT5 JP17, LEDDS10
J24 OUT6 JP15, LEDDS11
J25 OUT7 JP14, LEDDS12
J26 OUT8 JP16, LEDDS13
JP27 RETURN Selects HI or LOfor J23-J26
Pin No. Designation Notes
1 RETURN 0 or Battery, 22-29 VDC
2 OUTPUT HI (BAT) or LO (GND)
