Chapter 3: Setup
Figure 3-3. Spring-loaded Latch
2.
Remove the front panel, and set it aside.
This will be used as a ramp, to roll the transporter off of the crate base.
Removing the Cart
The cart is strapped, on its side, to a shelf in the upper part of the transporter crate.
1.
Slide the shelf out of the crate far enough to access the restraining strap.
2.
Remove the cardboard box from the cart shelf.
CAUTION: Due to the weight and height of this cardboard box, two
people should work together to lift it down.
This contains the dock and the joystick, as well as miscellaneous cords.
If accessories, such as call boxes, are ordered, they will be on the shelf, but not in the
large cardboard box.
You may need to loosen the strap to remove the box or boxes.
3.
Remove the straps from the cart, and then the cart itself.
CAUTION: Due to the weight and height of the cart, two people should
work together to lift it down.
4.
Remove the shelf from the crate.
To Next Page
