LD Cart Transporter User's Guide, 14766-000 Rev B
Page 39 of 190
Chapter 3: Setup
HMI Post
Laser Support Arm x 2
Support Arm Brace x 2
Rear
Brace
Front
Brace
Figure 3-6. LD Cart Transporter on Crate Base
Mounting the Side Laser Support Tubes
This procedure involves minor routing of wiring for the rear-facing laser. This wiring must be
in place before the support tubes are fully-installed.
