LD Cart Transporter User's Guide, 14766-000 Rev B
Page 52 of 190
Chapter 3: Setup
Figure 3-20. Rear View of Docking Station with Shoulder Bolts
3.
Lower the docking station down, so the two shoulder bolts on the back of the docking
station slide into the bracket, to secure the docking station to the wall.
Floor-mount, without Floor Plate
NOTE:Because this method permanently attaches the dock to the floor, it may be
subject to building code regulations. It is the user’s responsibility to verify that the
installation is in compliance with local regulations.
Screw the base of the docking station directly to the floor, using three user-supplied screws. For
dimensions of the available holes in the base, refer to Figure 3-19. We recommend M5 self-tap-
ping or M4 drywall screwsfor this.
Floor-mount, with Floor Plate
This mounting method uses the floor plate. The floor plate is not shipped attached to the dock-
ing station, so you must attach it for this type of mount. It will be in the crate with the docking
To Next Page
