128
A-4-9 NQ to Schneider Nano
/i
8 PIN MINI DIN CONNECTOR PINOUTS DB9 MALE PINOUTS
Signals Pin number Pin number Signals
A1 1TX+
B2 2
33
44RX+
55SG
66
SG 7 7
88TX-
9RX-
shield wire to body shield wire to DB9 body
12
34 5
67 8
