USB host functionality Section 5-3
55
5-3 USB host functionality
The USB host port can be used to perform a download or an upload of an
application to or from an USB stick. This enables the user to update the NQ-
Series or download logging data without the use of a Personal computer.
The NQ-Series only supports USB sticks that are formatted FAT or FAT32.
The following USB sticks are supported.
/i
Table 5.1: Supported USB sticks
Note
Make sure to backup all data on the USB stick before connecting it with the
NQ-Series.
To establish a connection between the USB stick and the NQ-Series proceed
as follows:
1 Place the USB stick in the USB host port.
2An empty NQ-Series (no application or no firmware) will automatically start
the USB Host function when the NQ-Series detects an USB stick.
3 When running an application setting system bit s037 to 1 will start USB
host function provided the USB stick is connected.
4
Figure 5.4: USB host functionality confirmation
5 Click YES to continue.
Brand Product Capacity (GB)
Transcend
JF V30
1
Transcend JF V30 2
Transcend JF V30 4
Transcend JF V30 8
SanDisk Cruzer Micro 2
SanDisk Cruzer Micro 4
Kingston DataTraveler 4
PNY Micro Attache 4
Sony Micro Vault 2
