Omron NQ HMI User Manual

Specifications per model Section 2-4
5
2-4 Specifications per model
/i
Table 2.3: Specifications per NQ-Series model
Model NQ5-
MQ000B/
NQ5-
MQ001B
NQ5-
SQ000B/
NQ5-
SQ001B
NQ3-
TQ000B
NQ3-
MQ000B
Display
Display size 5.7 “ 5.7 “ 3.5 “ 3.8 “
Display type STN STN TFT STN
Monochrome/colour Mono Colour Colour Mono
Colours supported 16
gradations
256
colours
1
1. 4096 colours for bitmaps
256
colours
2
2. 32000 colours for bitmaps
16
gradations
Brightness (Cd/m
2
) Min. 200 Min. 200 Min. 200 Min. 160
Contrast ratio 4 55 300 3
Contrast adjustment
using touch screen
Yes Yes No Yes
Backlight types CCFL CCFL LED LED
Touch screen size 5.7 “ 5.7 “ 3.5 “ 3.8 “
Function keys 6655
Memory
Total (MB) 8884
Program (MB) 6.7 6.7 6.7 2.6
Communication interfaces
RS-232/485/422 port
(Com 1)
Yes Yes Yes Yes
RS-232 port (Com 2) Yes Yes NA NA
Power rating (W) 10101010
Weight 0.7 kg max. 0.7 kg max. 0.3 kg max. 0.3 kg max.
External dimensions
Width * Height (mm) 195 * 142 195 * 142 128 * 102 128 * 102
Thickness (mm) 50 50 44.5 44.5
