Preparing for programming Section 4-1
18
4-1 Preparing for programming
4-1-1 NQ-Designer
NQ-Designer is used to create and modify user interfaces for the NQ-Series.
The user interface is created in the software and downloaded to the device.
Existing user interfaces can be uploaded to the software and be modified as
required. The software can also be used in a simulation mode to test the
program without downloading the program to the NQ-Series.
Figure 4.1: NQ-Designer
4-1-2 System requirements
The following basic PC hardware configuration is needed to install and use
NQ-Designer.
4-1-2-1 Microsoft® Windows® XP configuration
/i
Table 4.1: Windows XP configuration
Device Recommendations
Processor Minimum: 600 MHz Pentium processor or
equivalent processor
Recommended: 800 MHz Pentium processor or
equivalent processor
Operating System Windows® 2000 with SP4,
Microsoft® Windows® XP Professional
Microsoft® Windows® XP Home Edition with SP2
System RAM Minimum: 128 MB
Recommended: 256 MB/512 MB
Hard Disk Space 800 MB
(including 200 MB for the .NET Framework Redistributable)
