3-8 Installing the Controller Link Interface Unit
3-52
 Connecting the Cable
Connect the functional ground terminal of the PT and the cover with the cable to prevent
malfunction due to noise.
Connect with the cable provided.
 Removing Controller Link Interface Unit
1. Remove the cover.
Remove these screws and
remove the cover.
Cover
Controller Link
Support
Board
