5-3 Connecting to Host via EtherNet/IP
5-27
5-3 Connecting to Host via EtherNet/IP
5-3-1 What is EtherNet/IP?
EtherNet/IP is a multi-vendor industrial network protocol that uses Ethernet. The specification
is an open standard managed by the ODVA (Open DeviceNet Vendor Association), as is De-
viceNet, and it is used for a variety of industrial devices.
NS-series PTs can communicate with CS/CJ-series EtherNet/IP Units and CJ2H-CPU@@-
EIP and CJ2M-CPU3@ CPU Units. (The CJ2H-CPU@@-EIP and CJ2M-CPU3@ have built-in
EtherNet/IP ports.)
Also, it is possible to perform tag message communications when using a CPU Unit with a
built-in EtherNet/IP port. These CPU Units contain a tag name server, so if tag names and an
address table are stored in advance in the CPU Unit, it is possible to perform access from
the NS-series PT using only the tag names.
The following NS-series PTs and systems versions support EtherNet/IP.
Model
NS15-TX01@-V2, NS12-V2, NS10-V2, NS8-V2, NS5-SQ1@-V2,
NS5-TQ1@-V2, NS5-MQ1@V2
System version Version 8.0 or higher
The following NS-series PTs and PLCs can be connected using EtherNet/IP.
PLC Series Using the built-in board Using an EtherNet/IP Unit EtherNet/IP Unit
CS Series
CS1G-CPU@@(-V1)
CS1G-CPU@@H
CS1H-CPU@@(-V1)
CS1H-CPU@@H
CS1D-CPU@@H
CS1W-EIP21
CJ Series
CJ2H-CPU@@-EIP
CJ2M-CPU3@
CJ1H-CPU@@H
CJ1H-CPU@@H-R
CJ1G-CPU@@H
CJ1M-CPU@@
CJ2H-CPU@@(-EIP)
CJ2M-CPU@@
CJ1W-EIP21
Refer to SYSMAC CS/CJ/NE1S Series EtherNet/IP Unit Operation Manual (Cat. No. Z909)
for details on EtherNet/IP.
