Appendix 2 Dimensions
A-12
Appendix 2 Dimensions
● NS15
(Includes Mounting Dimensions)
Mounting panel
Mounting bracket
Note: The NS15 conforms to version-2 hardware standards.
With Controller Link Interface Unit Mounted With Video Input Unit Mounted
Mounting panel
Mounting bracket
Mounting panel
Mounting bracket
