Appendix 1 Specifications
A-11
• Video Input Specifications
Item Specifications
Input system NTSC (RS-170A compliant) or PAL
Scanning system (See note.) Interlaced
Input signal 1.0 V p-p 75 Ω
Signal input connector BNC connector
Note: The NS-series PTs do not support progressive scanning (i.e., non-interlaced scanning)
Item Specifications
Model NS-CA001 NS-CA002
Dimensions 150 x 90 x 21 mm (WxHxD) 150 x 102 x 22 mm (WxHxD)
Weight 0.5 kg or less
Ambient operating
temperature
•
NS12-V1/-V2 and NS10-V1/-V2
Mounting angle of 0° or greater but
less than 30° to horizontal: 0 to
35°C
Mounting angle of 30° or greater
but less than 90° to horizontal: 0 to
50°C
•
NS8-V1/-V2
Mounting angle of 0° or greater but
less than 30° to horizontal: 0 to
35°C
Mounting angle of 30° min. but less
than 90° to horizontal plane: 0 to
45°C
Mounting angle of 90° to horizon-
tal: 0 to 50°C
•
NS12-V1/-V2, NS10-V1/-V2,
and NS8-V1/-V2
Mounting angle of 0° or
greater but less than 30° to
horizontal: 0 to 35°C
Mounting angle of 30° or
greater but less than 90° to
horizontal: 0 to 45°C
Mounting angle of 90° to hori-
zontal: 0 to 50°C
Ambient storage
temperature
−20 to 60°C
Ambient operating
humidity
35% to 85% (with no condensation)
Rated power supply
voltage (See note.)
Power supply used from NS-series PT expansion interface connector
(5 V ±5%, 3.3 V ±5%).
Ambient operating
atmosphere
No corrosive gases.
Vibration resistance Conforms to NS-series PT specifications.
Shock resistance Conforms to NS-series PT specifications.
Note: You can still use 5 V from either port A or port B on the NS-series PT after you mount a
Video Unit on the PT.
