Appendix 1 Specifications
A-6
Specifications Item
NS5-SQ0@-V1
NS5-SQ@@-V2
(See note 6.)
NS5-TQ@@-V2 NS5-MQ@@-V2
Display device STN color LCD TFT color LCD High-luminance TFT
color LCD (See note
7.)
Monochrome STN LCD
Number of dots 320 dot horizontal × 240 dot vertical
Display color 256 colors (4,096
colors for
BMP/JPEG im-
ages)
256 colors (32,768 colors for BMP/JPEG
images) Monochrome/16 gray-
scale levels
Display area Width 117.2 mm × Height 88.4 mm (5.7 inches)
Display panel
(See note 5.)
View angle Left 50°,
Right 50°,
Top 30°,
Bottom 50°
Left 70°,
Right 70°,
Top 70°,
Bottom 50°
Left 45°,
Right 45°,
Top 20°,
Bottom 40°
Life expectancy 50,000 hours min.
(See note 1.)
75,000 hours min. (See note 1.) 50,000 hours min. (See
note 1.)
Brightness
adjustment
There are 3 levels of adjustment by operating the touch panel. (See note 2.)
Backlight (See
note 4.)
Backlight error
detection
No detection func-
tion.
Error is detected automatically, and the RUN indicator flashes green as
notification. (See note 3.)
Front panel
indicators
RUN Lit green: PT is operating normally.
Flashing green: The Memory Card transfer has ended normally or a backlight error was
detected immediately after power was turned ON. (Backlight errors are
not detected for the NS5-V1.)
Lit orange: Immediately after power turns ON, indicates file system check in pro-
gress, battery low, or disconnected and operating normally.
Flashing orange: Memory Card transfer in progress.
Note 1. This is the estimated time before brightness is reduced by half at room temperature and
humidity. It is not a guaranteed value. (It is based on the middle brightness setting using
the NS8.)
The life expectancy will be drastically shortened if PT is used at low temperatures. For ex-
ample, using the PT at temperatures of 0
°C will reduce the life expectancy to approxi-
mately 10,000 hours (reference value).
2. The brightness cannot be adjusted much.
3. This function does not detect service life expectancy.
It detects when the backlight is not lit due to a disconnection or other errors. Backlight er-
ror detection indicates that all backlights (2) are OFF.
4. Contact your nearest OMRON representative to replace the backlight.
5. There may be some defective pixels in the display. This is not a fault as long as the num-
bers of defective light and dark pixels fall within the following standard ranges.
Model Standard range
NS15-TX01@-V2
NS12-TS@@-V1/-V2
NS10-TV@@-V1/-V2
NS8-TV@@-V1/-V2
Number of light and dark pixels:
10 or less. (Must not be 3 consecutive.)
NS5-SQ@@-V1/-V2
NS5-MQ@@-V2
NS5-TQ@@-V2
Number of light and dark pixels:
4 or fewer defects the size of 0.2 < (minor axis + major axis)
/ 2 ≤ 0.55 mm (within 1 per 20-mm square)
6. Specifications are as follows for NS5-SQ@@-V2 PTs with lot number 2110 (manufactured
January 21, 2010) or earlier.
Item Specification
Display device STN color LCD
Display colors 256 colors (4,096 colors for BMP/JPEG images)
View angle
Left 50°, Right 50°, Top 45°, Bottom 50°
Refer to NS-series PT Lot Numbers on page A-8 for information on lot numbers.
