Appendix 8 Standard Models
A-51
PLC Series Unit Serial Communications Board or
Unit required for connection
CJ Series CJ1G-CPU42H
CJ1G-CPU43H
CJ1G-CPU44H
CJ1G-CPU45H
CJ1M-CPU11
CJ1M-CPU12
CJ1M-CPU13
CJ1M-CPU21
CJ1M-CPU22
CJ1M-CPU23
CJ1H-CPU65H
CJ1H-CPU66H
CJ1H-CPU67H
CJ1H-CPU65H-R
CJ1H-CPU66H-R
CJ1H-CPU67H-R
CJ2H-CPU64(-EIP)
CJ2H-CPU65(-EIP)
CJ2H-CPU66(-EIP)
CJ2H-CPU67(-EIP)
CJ2H-CPU68(-EIP)
CJ2M-CPU11
CJ2M-CPU12
CJ2M-CPU13
CJ2M-CPU14
CJ2M-CPU15
CJ2M-CPU31 (See note 3.)
CJ2M-CPU32 (See note 3.)
CJ2M-CPU33 (See note 3.)
CJ2M-CPU34 (See note 3.)
CJ2M-CPU35 (See note 3.)
CJ1W-SCU31/41 Serial Communica-
tions Unit
CP Series
CP1E-N@@@@-@
CP1L-@@@@@-@
CP1H-@@@@@-@
RS-422A Option Board: CP1W-CIF11
or CP1W-CIF12
C200HE-CPU32(-Z)
C200HE-CPU42(-Z)
C200HG-CPU33(-Z)
C200HG-CPU43(-Z)
C200HG-CPU53(-Z)
C200HG-CPU63(-Z)
C200HX-CPU34(-Z)
C200HX-CPU44(-Z)
C200HX-CPU54(-Z)
C200HX-CPU64(-Z)
C200HX-CPU65-Z
C200HX-CPU85-Z
C200HW-COM03/COM06(-V1) Com-
munications Board
C Series
CQM1H-CPU21
CQM1H-CPU51
CQM1H-CPU61
CQM1H-SCB41 Serial Communica-
tions Board
Reference • Both the normal 1:N NT Links and high-speed NT Links are supported for CS-
series PLC CPU Units with "-V1" in the model number. If the most recent Serial
Communications Unit or Board is used, these connections are also supported by
CPU Units without "-V1." Refer to 4-3 High-speed 1:N NT Link for details.
