Appendix 11 Differences between "-V1"/"-V2" Models and Other Models
A-69
The differences between "-V1" and "-V2" models and other models are shown below. For
details on the differences in software functions, refer to the Programming Manual.
Without "-V1" or "-V2" With "-V1"
NS12-TS0@ NS10-TV0@ NS7-
SV0@
NS12-TS0@-
V1
NS10-TV0@-
V1
NS8-
TV@@-V1
NS5-SQ0@-
V1
Display device High-definition TFT color
LCD
STN color
LCD
High-definition TFT color LCD STN color
LCD
Display color 256 colors 256 colors (32,768 colors for BMP/JPEG images, NS5: 4,096
colors for BMP/JPEG images)
Display area 12.1 inches 10.4 inches 7.7 inches 12.1 inches 10.4 inches 8.0 inches 5.7 inches
View angle Left/right
±60°,
Top 45
°,
Bottom 55
°
Left/right,
±60°,
Top 35
°,
Bottom 65
°
Left/right
±60°,
Top 35
°,
Bottom 65
°
Left/right
±60°,
Top 45
°,
Bottom 55
°
Left/right
±60°,
Top 35
°,
Bottom 65
°
Left/right
±60°,
Top 50
°,
Bottom 60
°
Left/right
±50°,
Top 30
°,
Bottom 50
°
Expansion
memory
interface
With Without Without
USB HOST Without With Without
USB Slave Without With
Ethernet
conformance
standard
10Base-T
(Ethernet models only)
10Base-T/100Base-T
(Ethernet models only)
Replacement
Battery
C500-BAT08 CPM2A-
BAT01
CJ1W-BAT01
With "-V2"
NS12-TS0@-V2 NS10-TV0@-V2 NS8-TV@@-
V2
NS5-SQ@@-V2 (See
note 1.)
NS5-TQ@@-V2 NS5-MQ@@-
V2
Display device High-definition TFT color LCD TFT color LCD High-definition
TFT color LCD
(See note 2.)
Monochrome
STN LCD
Display color 256 colors (32,768 colors for BMP/JPEG images) 256 colors (32,768 colors for BMP/JPEG
images)
Monochrome/
16 grayscale
levels
Display area 12.1 inches 10.4 inches 8.4 inches 5.7 inches
View angle Left/right ±60°,
Top 45
°, Bottom
75
°
Left/right
±60°,
Top 35
°, Bottom
65
°
Left/right
±65°,
Top 50
°,
Bottom 60
°
Left/right
±70°,
Top 70
°, Bottom 50°
Left/right
±45°,
Top 20
°, Bottom
40
°
Expansion
memory
interface
Without
USB HOST With Without
USB Slave With
Ethernet
conformance
standard
10Base-T/100Base-T (Ethernet models only)
Replacement
Battery
CJ1W-BAT01
Note 1. Specifications are as follows for NS5-SQ@@-V2 PTs with lot number 2110 (manufac-
tured January 21, 2010) or earlier.
Item Specification
Display device STN color LCD
Display colors 256 colors (4,096 colors for BMP/JPEG images)
View angle Left 50°, Top 45°, Bottom 50°
Refer to NS-series PT Lot Numbers on page A-8 for information on lot numbers.
2. The NS5-TQ PTs (high-luminance TFT LCDs) are approx. 110 cad/m2 brighter than
the NS5-SQ PTs (TFT LCDs).
