Omron NS7 Series User Manual

6-1 Operating Modes and System Menu
6-5
4. Password Tab
Item Function Page
Level 1 Changes the level 1 password. P. 6-23
Level 2 Changes the level 2 password. P. 6-23
Level 3 Changes the level 3 password. P. 6-23
Level 4 Changes the level 4 password. P. 6-23
Level 5 Changes the level 5 password. P. 6-23
5. Comm Tab
Item Function Page
Comms. Auto-return
Selects whether automatic recovery is used when a communica-
tions error occurs.
P. 6-24
Timeout internal Sets and displays the timeout monitor time. P. 6-24
Retry Counts Sets and displays the number of communications retries. P. 6-24
Serial Port A Sets and displays whether serial port A is used, the communica-
tions method, and other details.
P. 6-25
Serial Port B Sets and displays whether serial port B is used, the communica-
tions method, and other details.
P. 6-25
Ethernet
Sets and displays whether Ethernet is used and communications
details.
P. 6-27
Controller Link
Sets and displays whether Controller Link is used and communi-
cations details.
P. 6-28
6. Data Check Tab
Item Function Page
Screen Number Sets the screen number that is displayed as a sample. P. 6-30
Show Address Displays the communications addresses set for the sample dis-
play.
P. 6-30
7. Special Screen Tab
Item Function Page
Alarm History Displays the alarm history screen. P. 6-32
Operation Log Displays the screen for recording the operation log. P. 6-33
Error Log Displays the screen for recording the error log. P. 6-34
Special Functions Displays the device monitor screen and communications test
screen. This function also starts external applications and per-
forms Video Configuration.
P. 6-35
System Version Displays the version display screen. P. 6-40
8. Hardware Check Tab
Item Function Page
LCD Check Checks the LCD. P. 6-41
Touch Switch Check Checks the touch switches. P. 6-42
