Omron NS7 Series User Manual

Appendix 2 Specifications
A-6
@ Operating Specifications
Specifications
Item
NS12-TS0@
NS10-TV0@ NS7-SV0@
Method: Resistive membrane
Number of switches: 1900
(50 horizontal ´ 38 verti-
cal)
16 ´ 16 dots for each
switch.
Number of switches: 1200
(40 horizontal ´ 30 verti-
cal)
16 ´ 16 dots for each
switch.
Number of switches: 768
(32 horizontal ´ 24 verti-
cal)
20 ´ 20 dots for each
switch.
Input: Pressure-sensitive
Touch panel
(Matrix type)
Service life: 1,000,000 touch operations.
@ External Interface Specifications
Specifications
Item
NS12-TS0@
NS10-TV0@ NS7-SV0@
Expansion memory
interface (See note.)
1 slot for expanding screen data capacity.
8-Mbytes/16-Mbytes expansion
-
Memory card
interface
1 ATA-Compact Flash interface slot.
Used to transfer and store screen data and to store history data.
Expansion interface
For Expansion Interface Units
Used to install a Controller Link Interface Unit or Video Input Unit.
Note: This interface is for NS-series PTs only. Units not specified in this manual cannot be in-
stalled.
@ Programming Device (Software for Creating Screen Data)
Item Specifications
Name NS-Designer
Model NS-NSDC1-V@
A-2-3 Communications Specifications
· Serial Communications
Item Specifications
Port A
Conforms to EIA RS-232C.
D-Sub female 9-pin connector
5-V output (250 mA max.) through pin 6
(See note.)
Port B
Conforms to EIA RS-232C.
D-Sub female 9-pin connector
5-V output (250 mA max.) through pin 6.
(See note.)
Note: The 5-V output of serial ports A and B cannot be used at the same time.
