Omron NS7 Series User Manual

2-1 Connecting the Host
2-5
N:1 Connection (Connecting Multiple Hosts to a Single PT)
Supported communications
methods
PT
commu-
nications
type
Host
com-
munica-
tions
type
Supported connection methods
1:1 NT
Link
1:N NT
Links
FINS
Data
Links
Refer-
ence
page
RS-232C RS-232C
Host
PT
Serial port A
RS-232C cable
Host
Serial port B
RS-232C cable
Yes Yes No No
P.4-2
P.4-10
Ethernet Ethernet
Host
PT
Host
HUB
Ethernet
10Base-T twisted-pair straight
cable
No No Yes No
P.5-2
Controller
Link (See
note.)
Control-
ler Link
Host
PT
Host
Controller Link
Interface Unit
Specified shielded
twisted-pair cable
No No Yes Yes P. 5-15
RS-232C
RS-
232C,
RS-422A
Host
PT
Serial port A
RS-232C cable
Host
Serial port B
NS-AL002
RS-232C/
RS-422A
Converter
RS-422A cable
An RS-422A line can be connected to
serial port A at the same time that an RS-
232C line is connected to serial port B.
Yes Yes No ---
P.4-2
P.4-10
Ethernet,
RS-232C
Ethernet,
RS-232C
Host
PT
Ethernet
Host
RS-232C cable
10Base-T twisted-pair cross cable
Yes Yes Yes ---
P.4-2
P.4-10
P.5-2
