Omron NT2S-SF121B-E - QUICK START V1.03 - Allen-Bradley Cables

Version 1.03 Page 24
Allen-Bradley Cables
MicroLogix (DF1 protocol)
NT2S-SF121B-E Port PIN #
Male DB9 on cable
AB Micrologix 1000 & 1500
8 PIN MINIDIN (from AB)
2 TXD (RS232) 4 RXD
3 RXD 7 TXD
5&9 Ground 2 Ground
2 to shield
Allen Bradley SLC 5/0x (DF1 protocol)
NT2S-SF121B-E Port PIN #
Male DB9 on cable
AB SLC 5/0x
Male DB9 on cable
2 TXD (RS232) 2 RXD
3 RXD 3 TXD
5&9 Ground 5 Ground
5 to shield
