15. NT2S SPECIFICATIONS
Features Description NT2S-SF121B-E NT2S-SF122B-E
Programming package Windows Software Package - NT2ST Yes Yes
ASCII Controlled Messages ASCII in PLC registers is displayed on the NT2S screen. Pointer in PLC
memory tells NT2S which register to display. Pointers placed in that
PLC register point to data value to be displayed.
No No
Multi-vendor support Omron, Allen-Bradley Micrologix and SLC 5/0x, GE Micro, Modicon,
Keyence KV Series, Toshiba T Series, Koyo 305, 405, and DL205
Series.
Yes No
Memory type EEPROM 8k 8k
Power 24vdc Terminals or PLC Peripheral Port 5 vdc 24 vdc 5 vdc
Enclosure ratings IP65 Yes Yes
Standards CE, cCSAus Yes Yes
Ambient Op Rating 0 to 50 C Ok Ok
Storage temp -20 to + 60 C Ok Ok
Ambient Humidity 35 to 85 % with no condensation Ok Ok
Ambient Environment No corrosive gasses Ok Ok
Weight 400 g Ok Ok
Panel Fitting 2 clamps Ok Ok
Face Dimensions Dimensions of NT2S Front Bezel (mm) 109W x 60H 109W x 60H
Rear Unit Dimensions Dimensions for portion of NT2S that enters panel (mm) 91W x 44H x 44D 91W x 44H x 44D
Panel Cutout Recommended panel cutout Dimensions (mm) 1/8 DIN 92W x 45H 92W x 45H
Display Specifications
Display Lines * Characters 2 * 16 2 * 16
Character Height mm 4.35 mm 4.35 mm
Backlit LED Backlight Ok Ok
Effective display area mm 60 x 13 mm 60 x 13 mm
Indicators Red and Green LED indicators. Yes Yes
Number of screens Max number of screens if only text messages are used. Adding function
keys, scrolling messages, etc. decreases the maximum number of
screens.
250 250
Data Format HEX, BCD, OCT, BIN, signed, unsigned Ok Ok
Function Keys
Available Function keys Number of user programmable function keys 6 6
Global Function Key Program Function key can be programmed for global functions. Key program is
effective throughout the NT2S program.
Yes Yes
Local Function Key Program Function key can be programmed uniquely for each screen. Yes Yes
Function Key Binary Action Momentary, Toggle On, Toggle Off, Set On, Set Off. Yes Yes
Function Key Numeric Action Set constant value, increment, or decrement by a constant value to PLC
register.
Yes Yes
Numeric Entry Special screen uses arrow, clear, and enter keys to input numeric values
to PLC register.
Yes Yes
Function Key Screen Global Function key actions can be linked to a Function Key screen that
displays upon activation of that function key. This can be used to
confirm function key action.
Yes Yes
Password Protect Any Key Password can be activated for any function key. Yes Yes
