Omron NT2S-SF121B-E - QUICK START V1.03 - Koyo Cables

Version 1.03 Page 29
Koyo Cables
Koyo 405 Series
NT2S-SF121B-E Port PIN #
Male DB9 on cable
Koyo 405 Series
8PIN Minidin Connector
2 TXD (RS232) 3 RXD
3 RXD 2 TXD
5&9 Ground 13, 14, 15 Ground
13, 14, 15 Shield
1, 7, 8 Short
Koyo DL 205
NT2S-SF121B-E Port PIN #
Male DB9 on cable
Koyo 205 Series
6 x 6 Modular
2 TXD (RS232) 3 RXD
3 RXD 4 TXD
5&9 Ground 1 Ground
1 Shield
Koyo DL 305
NT2S-SF121B-E Port PIN #
Male DB9 on cable
Koyo 305 Series
4 x 4 Modular
2 TXD (RS232) 1 RXD
3 RXD 2 TXD
5&9 Ground 4 Ground
4 Shield
