Version 1.03 Page 28
Toshiba Cables
Toshiba PLC T1
NT2S-SF121B-E Port PIN #
Male DB9 on cable
Toshiba PLC T1
8 PIN Minidin Connector
2 TXD (RS232) 8 RXD
3 RXD 6 TXD
5&9 Ground 5 Ground
5 to shield
Toshiba PLC T2
NT2S-SF121B-E Port PIN #
Male DB9 on cable
Toshiba PLC T2
8 PIN Minidin Connector
2 TXD (RS232) 2 RXD
3 RXD 3 TXD
5&9 Ground 5 Ground
5 to shield
