Version 1.03 Page 26
Modicon Cables
Modicon (Modbus master)
NT2S-SF121B-E Port PIN #
Male DB9 on cable
Modicon Modbus Master
8 x 8 Modular Connector
2 TXD (RS232) 4 RXD
3 RXD 3 TXD
5&9 Ground 5 Ground
5 to shield
