Version 1.03 Page 31
Communications
COM port 1 Programming & Printing port DB9 connector
RS-232 Port
DB9 connector
RS-232 Port
COM port 2 Host PLC Communications DB9 connector
CMOS/RS-232 port
DB9 connector
CMOS port
Special functions
Real Time Clock 2-digit Year, Month, Date, Hour, Minute, Second Yes NA
2 User definable LEDs Red and Green LED can be controlled from PLC Yes Yes
Scrolling Messages Scroll messages up to 256 characters. Yes Yes
Flashing Display Specify for backlight to flash. Yes Yes
Minimum Display Time Define minimum display time for a screen. Yes Yes
Screen chaining Chained screens will display in sequential fashion, each displaying for
the set minimum display time.
Yes Yes
Link Screen Create a list of screens that can be navigated using the NEXT (F1) and
PREVIOUS (F2) keys.
Yes Yes
Bar Graph Display Display numeric values as a bargraph. Yes Yes
Print Functions
Print Screen Configure serial communications port to commumicate with a printer.
Print screen text and displayed PLC data values can be printed.
Yes Yes
