Omron NX-SL series User Manual

4 - 35
4 Safety Function Blocks
NX-series Safety Control Unit Instructions Reference Manual (Z931)
4
SF_EnableSwitch
 FB-specific State Codes (No Error)
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
0000 0 Idle The FB is disabled (default).
Ready = FALSE
S_EnableSwitchOut = FALSE
Error = FALSE
8004 32772 Basic Operation Mode Safe operation mode is OFF.
Ready = TRUE
S_EnableSwitchOut = FALSE
Error = FALSE
8005 32773 Safe Operation Mode Safe operation mode is ON.
Ready = TRUE
S_EnableSwitchOut = FALSE
Error = FALSE
8006 32774 Position 1 Safe operation mode is ON and the enable switch
is in position 1.
Ready = TRUE
S_EnableSwitchOut = FALSE
Error = FALSE
8007 32775 Position 3 Safe operation mode is ON and the enable switch
is in position 3.
Ready = TRUE
S_EnableSwitchOut = FALSE
Error = FALSE
8000 32768 Position 2 Safe operation mode is ON and the enable switch
is in position 2.
Ready = TRUE
S_EnableSwitchOut = TRUE
Error = FALSE
