Omron NX-SL series User Manual

2 Standard Functions
2 - 34
NX-series Safety Control Unit Instructions Reference Manual (Z931)
DINT_TO_WORD
This function converts a DINT variable to a WORD variable.
If you omit an input or output parameter, a building error will occur.
This function converts DINT data In to WORD data Out.
To convert WORD data to DINT data, refer to WORD_TO_DINT.
• The input condition depends on whether the output is safety data or standard data. If the condition is
not met, a building error will occur.
• If you set a safety data type variable for the output terminal, set a safety data type variable for the
input terminal as well.
• If you set a standard data type variable for the output terminal, you can set either a safety data type
variable or a standard data type variable for the input terminal.
• If the input value is not DINT#0 to DINT#65535, a cast error will occur and the program will stop.
Instruction Name FB/FUN Graphic expression
DINT_TO_WORD Convert DINT to
WORD
FUN
Variables
Name I/O Description Valid range Default
In Data to con-
vert
Input Data to con-
vert
DINT#0 to 65535 DINT#0
Out Conversion
result
Output Conversion
result
WORD#16#0000 to FFFF WORD#16#0000
Boolean Bit strings Integers Durations
BOOL SAFEBOOL BYTE SAFEBYTE WORD SAFEWORD DWORD SAFEDWORD INT SAFEINT DINT SAFEDINT TIME SAFETIME
In OK OK
Out OK OK
Function
Additional Information
Precautions for Correct Use
DINT_TO_WORD
