2 - 17
2 Standard Functions
NX-series Safety Control Unit Instructions Reference Manual (Z931)
Data Type Conversion Instructions
2
BYTE_TO_DINT
BYTE_TO_DINT
This function converts a BYTE variable to a DINT variable.
If you omit an input or output parameter, a building error will occur.
This function converts BYTE data In to DINT data Out.
To convert DINT data to BYTE data, refer to DINT_TO_BYTE.
• The input condition depends on whether the output is safety data or standard data. If the condition is
not met, a building error will occur.
• If you set a safety data type variable for the output terminal, set a safety data type variable for the
input terminal as well.
• If you set a standard data type variable for the output terminal, you can set either a safety data type
variable or a standard data type variable for the input terminal.
Instruction Name FB/FUN Graphic expression
BYTE_TO_DINT Convert BYTE to
DINT
FUN
Variables
Name I/O Description Valid range Default
In Data to con-
vert
Input Data to con-
vert
BYTE#16#00 to FF BYTE#16#00
Out Conversion
result
Output Conversion
result
DINT#0 to 255 DINT#0
Boolean Bit strings Integers Durations
BOOL SAFEBOOL BYTE SAFEBYTE WORD SAFEWORD DWORD SAFEDWORD INT SAFEINT DINT SAFEDINT TIME SAFETIME
In OK OK
Out OK OK
Function
Additional Information
Precautions for Correct Use
BYTE_TO_DINT
