4 Safety Function Blocks
4 - 40
NX-series Safety Control Unit Instructions Reference Manual (Z931)
 Error Detected
The discrepancy time between S_ChannelA and S_ChannelB is monitored when either of them
changes to TRUE or FALSE.
 Operation for Errors
• If an error is detected, S_EquivalentOut changes to FALSE and Error changes to TRUE. Diag-
Code shows the error state.
• If an error occurs in an input, make the inputs for both channels inactive (make S_ChannelA and
S_ChannelA FALSE) to reset the FB.
 FB-specific Error Codes
 FB-specific State Codes (No Error)
Instruction Execution Errors
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
C001 49153 Error 1 S_ChannelB did not change to TRUE within Moni-
toringTime in the Wait for Channel B state (8004).
Ready = TRUE
S_EquivalentOut = FALSE
Error = TRUE
C002 49154 Error 2 S_ChannelA did not change to TRUE within Moni-
toringTime in the Wait for Channel A state (8014).
Ready = TRUE
S_EquivalentOut = FALSE
Error = TRUE
C003 49155 Error 3 The input did not change within the monitoring time
while changing from the From Active Wait (8005) to
the Init (8001) state. S_ChannelA or S_ChannelB
did not change to FALSE within the monitoring time
after the other input changed to FALSE.
Ready = TRUE
S_EquivalentOut = FALSE
Error = TRUE
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
0000 0 Idle The FB is disabled (default).
Ready = FALSE
S_EquivalentOut = FALSE
Error = FALSE
8001 32769 Init The FB detected an activate signal and the FB is
active.
Ready = TRUE
S_EquivalentOut = FALSE
Error = FALSE
8000 32768 Safety Output Enabled An input changed to TRUE in Equivalent Mode.
Ready = TRUE
S_EquivalentOut = TRUE
Error = FALSE
