4 Safety Function Blocks
4 - 60
NX-series Safety Control Unit Instructions Reference Manual (Z931)
8000 32768 Normal The safety guard is closed and a confirmation
response for a safe state was received.
Ready = TRUE
S_GuardMonitoring = TRUE
Error = FALSE
8001 32769 Init The FB was activated.
Ready = TRUE
S_GuardMonitoring = FALSE
Error = FALSE
8002 32770 Open Guard Request The FB is waiting for S_GuardSwitch1 and
S_GuardSwitch2 to change to FALSE.
Ready = TRUE
S_GuardMonitoring = FALSE
Error = FALSE
8003 32771 Wait for Reset The FB is waiting for Reset to change to
TRUE.
Ready = TRUE
S_GuardMonitoring = FALSE
Error = FALSE
8012 32786 Guard Opened The guard is completely open.
Ready = TRUE
S_GuardMonitoring = FALSE
Error = FALSE
8004 32772 Wait for GuardSwitch2 S_GuardSwitch1 changed to TRUE (waiting
for S_GuardSwitch2). The discrepancy timer
started.
Ready = TRUE
S_GuardMonitoring = FALSE
Error = FALSE
8014 32788 Wait for GuardSwitch1 S_GuardSwitch2 changed to TRUE (waiting
for S_GuardSwitch1). The discrepancy timer
started.
Ready = TRUE
S_GuardMonitoring = FALSE
Error = FALSE
8005 32773 Guard Closed The guard was closed. If S_AutoReset is
FALSE, the FB is waiting for Reset.
Ready = TRUE
S_GuardMonitoring = FALSE
Error = FALSE
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
