Omron NX-SL series User Manual

4 - 119
4 Safety Function Blocks
NX-series Safety Control Unit Instructions Reference Manual (Z931)
4
SF_TestableSafetySensor
C003 49155 Reset Error 3 When state C010 (Test Error 1) was entered, an
undetected change to TRUE in the Reset input
was detected.
Ready = TRUE
S_OSSD_Out = FALSE
S_TestOut = TRUE
TestPossible = FALSE
TestExecuted = FALSE
Error = TRUE
C004 49156 Reset Error 4 When state C020 (Test Error 2) was entered, an
undetected change to TRUE in the Reset input
was detected.
Ready = TRUE
S_OSSD_Out = FALSE
S_TestOut = TRUE
TestPossible = FALSE
TestExecuted = FALSE
Error = TRUE
C005 49157 Reset Error 5 When state 8006 (End External Test) was
entered, an undetected change to TRUE in the
Reset input was detected.
Ready = TRUE
S_OSSD_Out = FALSE
S_TestOut = TRUE
TestPossible = FALSE
TestExecuted = FALSE
Error = TRUE
C006 49158 Reset Error 6 When state C000 (Parameter Error) was entered,
an undetected change to TRUE in the Reset
input was detected.
Ready = TRUE
S_OSSD_Out = FALSE
S_TestOut = TRUE
TestPossible = FALSE
TestExecuted = FALSE
Error = TRUE
C007 49159 Reset Error 7 When state 8013 (Wait for Reset 2) was entered,
an undetected change to TRUE in the Reset
input was detected.
Ready = TRUE
S_OSSD_Out = FALSE
S_TestOut = TRUE
TestPossible = FALSE
TestExecuted = TRUE
Error = TRUE
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
