2-128
• Strip the sheath as shown in the following diagram.
6 mm
D Terminal Blocks
XW2B-20G5
The XW2B-20G5 is an M3.5 screw terminal block.
D External Dimensions
Flat cable connector
(MIL connector)
Two, 3.5 dia.
Note The terminal pitch is 8.5 mm.
Standard Models and Specifications Chapter 2
