4-44
Pn000.1 Function selection basic switch –– Control mode selection (All operation modes)
Setting
range
0 to b Unit --- Default
setting
1 Restart
power?
Yes
Note Refer to 4-4-3 Important Parameters.
Pn000.2 Function selection basic switch –– Unit No. setting (All operation modes)
Setting
range
0 to F Unit --- Default
setting
0 Restart
power?
Yes
Setting Explanation
Setting Explanation
0 to F Sets the Servo Driver unit number
• You must make settings if connecting multiple Servo Drivers using OMNUC W-series Servo Driver
Computer Monitoring Software (for Windows95). Refer to the software for details.
Pn000.3 Function selection basic switch –– Not used.
Setting
range
--- Unit --- Default
setting
0 Restart
power?
Yes
Note Do not change setting.
D Function Selection Application Switch 1 (Pn001: Default setting 1002)
Pn001.0 Function selection application switch 1 –– Stop selection if alarm occurs when servo is OFF
(All operation modes)
Setting
range
0 to 2 Unit --- Default
setting
2 Restart
power?
Yes
Note Refer to 4-4-3 Important Parameters.
Pn001.1 Function selection application switch 1 –– Stop selection when drive prohibited is input
(Position, speed, internally-set speed control)
Setting
range
0 to 2 Unit --- Default
setting
0 Restart
power?
Yes
Note Refer to 4-4-3 Important Parameters.
Pn001.2 Function selection application switch 1 –– AC/DC power supply input selection (All operation
modes)
Setting
range
0, 1 Unit --- Default
setting
0 Restart
power?
Yes
Setting Explanation
Setting Explanation
0 AC power supply: AC power supplied from L1, L2, (L3) terminals
1 DC power supply: DC power from +1, – terminals
• Select setting 1 if using a DC power supply.
• If using a DC power supply, perform the following operations.
Control circuit power supply: Supply DC power to L1C and L2C. There is no polarity.
Operation Chapter 4
